FHP1404

Release time：2017-05-22 17:42:14

Industry generic name：IRF1404, HY4004Wait

View Specifications >

  • Feihong 1404,N-channel trench process MOS tube, suitable for 500W/12V input inverter front circuit. Alternative field effect tube: IRF1404, HY4004

Free sample Join List

Obtain free product samples

Your salutation：
Contact Information：
Product sample：

Product Parameters

Part Number Polarity Package Vgs（±V） VTH（V） ID(A) BVdss(V) Rds（on）(Ω)
Model Polarity Encapsulation form Vgs=10v
(typ)		 Vgs=10v
(max)
FHP1404
N
TO-220
25
2-4
180
40
2.5
3.3

Product Details

【Feihong 1404 Product Description】

Feihong 1404, an N-channel trench process MOSFET, is suitable for the front-end circuit of inverters with 500W/12V input.


【Feihong 1404 Product Features】

Feihong 1404 has low on-resistance and high power.
