FHP730B

Release time：2017-05-23 11:00:26

Industry generic name：6N40, 7N40, IRF730BWait

View Specifications >

  • Feihong 730 is an N-channel enhanced high voltage power FET. This product is mainly used in 150W/220V square wave output inverter circuit, DC-AC power converter, DC-DC power converter, high voltage H bridge PMW motor drive. Can replace other field effect tube brand model: 6N40, 7N40, IRF730B;

Free sample Join List

Obtain free product samples

Your salutation：
Contact Information：
Product sample：

Product Parameters

Part Number Polarity Package Vgs（±V） VTH（V） ID(A) BVdss(V) Rds（on）(Ω)
Model Polarity Encapsulation form Vgs=10v
(typ)		 Vgs=10v
(max)
FHP730B
N
TO-220
30
2～4
6
400
0.75
0.9

Product Details


【Product Description】


Feihong 730, is an N-channel enhancement type high voltage power MOSFET. The product is mainly used in the inverter circuit of 150W/220V square wave output, DC-AC power converter, DC-DC power converter, and high voltage H bridge PWM motor driver.It can replace otherMOSFET brands and models:6N40, 7N40, IRF730B;


【Product Features】


FHP730/FHF730, 6A, 400V, RDS(on) = 0.9Ω(max) @VGS = 10 V low charge, low reverse transfer capacitance, fast switching speed, low resistance;


【Application Examples】


FHP730 pin diagram
